Atom LED WiFi RF RGBW Receiver (TUYA App Compatible)
The Atom LED WiFi RF RGBW Receiver allows you to control your LED strip lighting directly from your smartphone via the TUYA Smart App — giving you full wireless control over brightness, colours, scenes, and effects.
Compatible with RGBW LED strips (12–24V DC), this compact controller supports both WiFi and RF remote control, making it ideal for smart home lighting, feature lighting, and commercial LED installations.
With a high 12A output capacity, it can power up to 144W at 12V or 288W at 24V, ensuring reliable performance even on longer lighting runs. Simple terminal connections make installation straightforward for professional or DIY users.
⭐ Key Features
-
✔ TUYA Smart App compatible (iOS & Android)
-
✔ WiFi + RF wireless control
-
✔ Supports RGBW LED strip lighting
-
✔ 12–24V DC input
-
✔ High power output — up to 288W @ 24V
-
✔ 12A maximum load
-
✔ Compact & easy-wire terminals
-
✔ Works with smart automations & scenes
📌 Specifications
| Specification | Details |
|---|---|
| Model | CX-W01-P4-12A |
| Input Voltage | 12–24V DC |
| Max Input Current | 12A |
| Output Channels | RGBW |
| Max Output Power | 144W @ 12V / 288W @ 24V |
| Control Method | WiFi + RF |
| App Support | TUYA Smart |
| Operating Temp | -25°C to +45°C |
| Mounting | Surface / Inline |
Note: When using DC terminal input, do not exceed 5A on both input and output.
